Product Description:
PPGI & PPGL is a product made of hot-dip galvanized steel sheet,
hot-dip galvalume steel sheet, electro galvanized steel sheet, etc.
After surface pretreatment, one or several layers of organic
coating are applied on the surface, and then baked and solidified.
The color coated steel coil is light in weight, beautiful in
appearance, and has good anti-corrosion performance, and can be
directly processed. The color is generally divided into gray, sea
blue, brick red, etc. It is mainly used in advertising,
construction, decoration, home appliances, electrical appliances,
Furniture industry and transportation industry. The coatings used
for color coated steel coils are based on the environment in which
the resin is selected, such as polyester silicon modified
polyester, polyvinyl chloride plastisol, polyvinylidene chloride,
and the like.
Technical Parameters:
Product Name | PPGI / PPGL Prepainted Galvanized Color Coated Coil |
Standard | ASTM, AISI, BS,DIN,GB,JIS,etc |
Grade | CGCC,CGCH,CGCD,CGLCC,CGLCD,SGCC,SGCH
G350,G450,G550,DX51D,DX52D,DX53D or Customer's
Requirement |
Painting Thickness | Top coating 15 - 25micron(10 + 5mic ~ 20 + 5mic), the back coating
is 5 - 10micron if the back coating is double, thickness can be
22micron |
Thickness | 0.10 - 6.0mm or customized as required |
Width | 500 - 1500mm or customized as required |
Zinc Coating | 30 - 275G / M2 |
Coil Weight | 3 - 5 Tons or customized as required |
Coil ID | 508mm / 610mm |
PPGI Color | According to RAL color or as clients samples |
Hardness | Soft hard(HRB60),medium hard(HRB60 - 85),full hard(HRB85 - 95) |
Tolerance | Thickness: +/- 0.02mm
Width:+/- 2mm
Paint:+/- 2mic |
Quality Test | SGS testing , test zinc coating thickness / PE coating thickness /
T testing and others by every coil |
Coating Type | PE,SMP,HDP,PVDF |
Transport Package | Export Standard Package(Plastic film in the first layer,second
layer is Kraft
paper. Third layer is galvanized sheet) or as Request. |
Payment Terms | T/T,L/C |
Surface Structure | Normal,Wrinkle,Matt,PVC film,Wood grain,Flower Grained,Special
pattern Highlight ,Embossed,High glossy etc |
Application | Construction and building: roofing; ventilating duct; handrail;
partition panel,etc.;Further processing: refrigerator; washing
machine; recorder; microwave,household appliance,industry faclities
etc. |
Delivery Time | Within 3 - 15 days after recieve 30% desipot or as your requirement |
Terms of Delivery | FOB, CFR, CIF, CNF or as required |
MOQ | 1 Ton |
Applications:
PPGI Galvanized Steel Coil produced by Pucheng is a high-quality
steel coil with the models Q235B, A36 and Q345. It is certified
with API, ce, RoHS, SNI, BIS, SASO, PVOC, SONCAP and SABS. The
package is standard and delivery time is 7 to 15 days. Payment
terms include TT/ LC / Western Union / DP / DC. The supply ability
is 2000 tons per month. The coil ID is 508 / 610mm and available
colors are from the RAL color system. The width is 600 to 1250mm
and the spangle is zero, regular and big. It is specially designed
for color coated coil, AZ41 - AZ60, color coated galvalume aluzinc
galvanized steel coil and pre painted galvanized steel coil.
Support and Services:
1.Good durability and long life compared with galvanized steel.
2.Good heat resistance, less discoloration at high temperature than
galvanized steel.
3.Good thermal reflectivity.
4.Processability and spraying performance similar to galvanized
steel.
5.Good welding performance.
6.Good performance - price ratio, durable performance and extremely
competitive price.
Packing and Shipping:
20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
40ft HC:12032mm(Lengh)x2352mm(Width)x2698mm(High)
20feet container load 25tons coils whose length is under 5.8m
40feet container load 25tons coils whose length is under 11.8m
* Packing: Mill's standard packing
* Shipment: 7 - 15 days for customized orders, immediate shipment
for stock
FAQ:
How is the product packaged and shipped?
Steel coils use seaworthy common package which contains corner
guards, shield protecters and fastening belts. Since we generally
offer FOB prices, the buyer is responsible for the freight affairs.
Can I get samples before order ?
Yes, of course. Usually our samples are free,we can produce by your
samples or technical drawings.
Does the product have quality inspection before loading?
Of course, all our products are strictly tested for quality before
packaging, and unqualified products will be destroyed.we accept the
third party inspection absolutely.
