6.00mm Galvanized Steel Coils Hot Rolled Metal 30 - 275g / M2 Dx51d

Ask Lasest Price
Brand Name :	TISCO
Model Number :	SGCC SECC SGCD PPGI DX51D DX54D S250GD S550GD
Certification :	ce, ISO9001,RoHS, IBR
Price :	Negotiable
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	20000 Ton/Tons per Month
Delivery Time :	3-15 days

Add to Cart

Product Details
Company Profile

6.00mm Galvanized Steel Coils Hot Rolled Metal 30 - 275g / M2 Dx51d

— Galvanized Steel Coil —

Description

Hot-dip galvanizing is the reaction of molten metal with an iron substrate to produce an alloy layer, thereby combining the
substrate and the plating layer. Hot-dip galvanizing is to pickle iron and steel parts first. In order to remove iron oxide on the surface of iron and steel parts, after pickling, it is cleaned in an ammonium chloride or zinc chloride aqueous solution or a mixed solution of ammonium chloride and zinc chloride.And then sent to the hot-dip plating bath. Hot-dip galvanizing has the advantages of uniform coating, strong adhesion and long service life.

Technical Standard	EN10147, EN10142, DIN 17162, JIS G3302, ASTM A653
Steel Grade	Dx51D, Dx52D, Dx53D, DX54D, S220GD, S250GD, S280GD, S350GD, S350GD, S550GD; SGCC, SGHC, SGCH, SGH340, SGH400, SGH440, SGH490,SGH540, SGCD1, SGCD2, SGCD3, SGC340, SGC340 , SGC490, SGC570; SQ CR22 (230), SQ CR22 (255), SQ CR40 (275), SQ CR50 (340), SQ CR80(550), CQ, FS, DDS, EDDS, SQ CR33 (230), SQ CR37 (255), SQCR40 (275), SQ CR50 (340), SQ CR80 (550); or Customer’s Requirement
Type	Coil/Sheet/Plate/Strip
Thickness	0.12-6.00mm,or customer's requirement
Width	600mm-1500mm, according to customer's requirement
Type of Coating	Hot Dipped Galvanized Steel(HDGI)
Zinc Coating	30-275g/m2
Surface Treatment	Passivation(C), Oiling(O), Lacquer sealing(L), Phosphating(P), Untreated(U)
Surface Structure	Normal spangle coating(NS), minimized spangle coating(MS), spangle-free(FS)
Quality	Approved by SGS,ISO
ID	508mm/610mm
Coil Weight	3-20 metric ton per coil
Package	Water proof paper is inner packing,galvanized steel or coated steel sheet is outer packing , side guard plate,then wrapped by seven steel belt.or according to customer's requirement
Export market	Europe, Africa, Central Asia, Southeast Asia, Middle East, South America, North America, etc

STEEL GRADE	CHEMICAL COMPOSITION %					MECHANIC PROPERTY			C.B OF	COATING
	C	Si	Mn	S	P	T.S	Y.S	E.L	COATING	COATING
	x103	x103	x102	x103	x103	Mpa	Mpa	%	d=0 180°	G/M²
JIS G3302 SGCC	12	30	41	31	21	480	300	13	OK	Z60-150
JIS G3302 SGCH	12	10	21	18	8	680	650	20	OK	Z60-150
ASTM A653 CS.B	29	30	60	35	30	386	250-380	20	OK	Z60-275
DX51D+Z	20	21	18	1.8	11	355	245	38	OK	Z60-275
G550	12	6	73	5	17	715	654	8	OK	Z60-275
