DX51D 0.12mm Galvanized Steel Coil 600 - 2000mm Width Sheet Strip

Ask Lasest Price
Brand Name :	TISCO
Model Number :	SGCC SECC SGCD PPGI DX51D DX54D S250GD S550GD
Certification :	ce, ISO9001,RoHS, IBR
Price :	Negotiable
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	20000 Ton/Tons per Month
Delivery Time :	3-15 days

Add to Cart

Product Details
Company Profile

DX51D 0.12mm Galvanized Steel Coil 600 - 2000mm Width Sheet Strip

— Galvanized Steel Coil —

Description

What is standard galvanized thickness?

What is the thickness of a galvanized coating? When it comes to the specification of hot dip galvanizing, most contractors know that to be standards compliant, 7mm steel requires an average coating thickness of '85 microns'.You can tell that metal is galvanized when it has a pattern to it that is known as a spangle pattern. A spangle pattern almost looks like someone dipped a sponge in gray paint and then sponge-painted the metal. You'll notice darker and lighter spots, much like you would see when a wall is sponge painted.

Standard	astm a526 a528 a444, a653, jis g3302, en10142 en1012, etc
Grade	DX51D+Z, DX52D+Z, DC52D+Z, DC51D+Z, S350GD+Z, G550, SGCC, DD52D+Z etc
Thickness	0.12-3.0mm (customize, above 3.0mm available)
Width	600-2000mm (customize)
Length	as customer requirements
Coil inner diameter	508mm/610mm (customize)
Zinc coating	20-600g/m2
Raw material	cold rolled base. (hot rolled base also available)
Technique	hot dipped. (electro also available)
Coil weight	3-8 tons
Tolerance	thickness +- 0.02 or +- 0.04, width +-5mm
Spangle type	zero spangle, small spangle, regular spangle, big spangle
Surface treatment	chromated/non-chromated, oiled/non-oiled, anti-fingerprints
Certification	CE, ISO9001-2008, SGS
Monthly output	17000 tons
Packaging	3 layers. kraft paper outside + water-proof plastic film in the middle + steel plate covered with strips outside
Landing port	qingdao/shanghai/tianjin port
Payment terms	T/T, L/C, western union paypal etc
Delivery time	it takes about 10 days for stock goods, or it will need 15-25 days if goods need to be customized
MOQ	as customer needs. reminder: more quantity reduce your purchase cost greatly
Inspection	third-party test
Cooperate brand	anshan steel, baotou steel, jiangsu shagang etc

Usage	Grade	Yield Strength (MPA)	Tensile Strength (MPA)	Elongation rate %
Punching galvanized steel	DX51D+Z	~	270-500	>=20
	DX52D+Z	140-300	270-420	>=22
	DX53D+Z	140-260	270-380	>=26
	DX54D+Z	140-220	270-350	>=30
Structure galvanized steel	S220GD+Z	>=220	>=300	>=18
	S250GD+Z	>=250	>=330	>=17
	S280GD+Z	>=280	>=360	>=16
	S320GD+Z	>=320	>=390	>=15
	S350GD+Z	>=350	>=420	>=14
	S400GD+Z	>=400	>=470	~
	S500GD+Z	>=500	>=530	~
	S550GD+Z	>=550	>=560	~
