Astm Inox Sus Stainless Steel Plates 4Mm 304 304L 316 410 316 100mm

Ask Lasest Price
Brand Name :	JIANGSULIANZHONG
Model Number :	GB AISI ASTM BS DIN JIS
Certification :	API, CE, SNI, SASO, sirm, tisi, KS, JIS, GS, ISO9001
Price :	Negotiable
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	2000MT/Month
Delivery Time :	3-15 days
MOQ :	As your requirement

Add to Cart

Product Details
Company Profile

Astm Inox Sus Stainless Steel Plates 4Mm 304 304L 316 410 316 100mm

— Stainless Steel Sheet —

Product Specification

Stainless plate products are used in industries that include but are not limited to food processing, chemical processing, power generation, high vacuum, waste water treatment, heat treatment, pulp and paper, pharmaceutical and brewing.

Stainless steel, any one of a family of alloy steels usually containing 10 to 30 percent chromium. In conjunction with low carbon content, chromium imparts remarkable resistance to corrosion and heat. Other elements, such as nickel, molybdenum, titanium, aluminum, niobium, copper, nitrogen, sulfur, phosphorus, or selenium, may be added to increase corrosion resistance to specific environments, enhance oxidation resistance, and impart special characteristics.

Product Name	Stainless Steel Plate
Material Type	Ferrite stainless steel, magnetic; Austenitic stainless steel, Non-magnetic.
Grade	Mainly201, 202, 304, 304L, 304H, 316, 316L,316Ti,2205, 330, 630, 660, 409L, 321, 310S, 410, 416, 410S, 430, 347H, 2Cr13, 3Cr13 etc
	300series:301,302,303,304,304L,309,309s,310,310S,316,316L,316Ti,317L, 321,347
	200series:201,202,202cu,204
	400series:409,409L,410,420,430,431,439,440,441,444
	Others:2205,2507,2906,330,660,630,631,17-4ph,17-7ph, S318039 904L,etc
	Duplex stainless steel:S22053,S25073,S22253,S31803,S32205,S32304
	Special Stainless Steel:904L,347/347H,317/317L,316Ti,254Mo
Technology	Cold Rolled /Hot Rolled
Length	2000/2438/2500/3000/3048 mm
Width	1000/1219/1250/1500 mm
Thickness	0.4-3mm(cold Rolled), 3-200mm(hot Rolled)
Surface	BA, 2B, 2D, 4K, 6K, 8K, NO.4, HL, SB, Embossed,perforated,water ripple
	Leveling: improve flatness, esp. for items with high flatness request.
	Skin-Pass: improve flatness, higher brightness
Other Choices	Cutting:Laser cutting, help the customer to cut the required size
Protection	1. Inter paper available
Protection	2. PVC protecting film available
Price Item	FOB,CIF,DDU,FCA,EXW ,.etc
Advantage	We have stock, about 20000 tons.

Inspection	1.Provide MTC (Mill Test). 2.Accept the inspection by the third party agent

Grade	C(%)	Si(%)	Mn(%)	P(%)	S(%)	Cr(%)	Ni(%)	N(%)	Cu(%)
304	≤0.08	≤1.00	≤2.00	≤0.045	≤0.03	18.00-20.00	8.00-10.50	≤0.10	/
304L	≤0.03	≤1.00	≤2.00	≤0.045	≤0.03	18.00-20.00	8.00-10.50	≤0.10	/
304H	0.04-1.00	≤1.00	≤2.00	≤0.045	≤0.03	18.00-20.00	8.00-10.50	≤0.10	/

Grade	Tensile Strength (Mpa)	Yield Strength (Mpa)	Elongation (%)	Rate Of Reduction In Area (%)	Density (G/Cm3)	Hardness (HB) (HRB) (HV)
304	≥515	≥205	≥40	/	7.93	≤201HBW;≤92HRB; ≤210HV
34L	≥515	≥205	≥40	/	7.93	≤187HB; ≤90HRB; ≤200HV
304H	≥515	≥205	≥40	/	7.93	/

Product Details

Surface

Surface Finished	Characteristics	application
NO.1	Finished by hot-rolling, smoother and pickling, characterized by white pickled surface.	Chemical industry equipment, Industrial tanks.
2B	Finished by anneal treatment, pickling after cold rolling, followed by skin pass line to more brighter and smoother surface.	General application medical instruments, Tableware.
BA	Bright anneal treatment after cold rolling.	Kichen utenstil, Kitchen ware,Architectural purpose.
NO.4(Satin)	Finished by incontinuous linear brushing	Architecture,industries,Escalators, Kitchen ware, Vehicles.
Hairline	Finished by continuous linear brushing	Architecture,industries,Escalators, Kitchen ware, Vehicles.
8K(mirror)	A mirror-like reflective surface by polishing with finer abrasives over 800 mesh.	Refletor, Mirror, Interior- Exterior decoration for building.
